WELD ON END

GREASE NIPPLE CAN BE PROVIDED (OPTIONAL)

CODE A B C D E
SWOE 164626 46 26 30 16 20
SWOE 164660 46 60 30 16 20
SWOE 186543 65 43 50 18 35
SWOE 196543 65 43 50 19 35
SWOE 226543 65 43 50 22.1 35
SWOE 226890 A 68 90 50 22.1 35
SWOE 226890 B 68 90 60 22.1 35
SWOE 227650 76 50 70 22.1 35
SWOE 257650 A 76 50 70 25.4 35
SWOE 257650 B 76 50 70 25.4 35
SWOE 287650 A 76 50 70 28.4 35
SWOE 287650 B 76 50 70 28.4 35
SWOE 257880 78 80 70 25.4 38
SWOE 287880 78 80 70 28.4 38
SWOE 228065 A 80 65 70 22/28 45
SWOE 228065 B 80 65 70 22/28 45
SWOE 258065 80 65 70 25.4 45
SWOE 288065 A 80 65 70 28.4 45
SWOE 288065 B 80 65 70 28.4 45
SWOE 258080 80 80 70 25.4 38
SWOE 288080 A 80 80 70 28.4 38
SWOE 288080 B 80 80 70 28.4 45
SWOE 228355 83 55 70 22.1 35
SWOE 258355 83 55 70 25.4 35
SWOE 288355 A 83 55 70 28.4 35
SWOE 288355B 83 55 70 28.4 45
SWOE 288075 80 75 79 28.4 45
SWOE 289665 96 65 70 28.4 45
SWOE 309665 96 65 70 30 45
SWOE 329665 96 65 70 32 45
SWOE 349665 96 65 70 34 45
SWOE 2810865 108 65 80 28.4 45
SWOE 3710865 108 65 80 37 45
SWOE 3810865 108 65 80 38 45
